Brand Name : | JINTE |
Model Number : | JT-G |
Certification : | ISO CE |
Price : | USD 7000-15000 / set |
Payment Terms : | L/C, D/A, D/P, T/T, Western Union |
Supply Ability : | 10 set / month |
Delivery Time : | 30 days |
Automatic Gabion Mesh Machine/Chicken Wire Netting Machine Manufacturer
GABION MESH MACHINE PRODUCT DETAILED PRODUCT DESCRIPTION
The series gabion mesh machines have been designed to make gabion mesh of various widths and mesh sizes. The possible coatings are heavily galvanized and zinc. For high corrosion resistance, zinc and PVC, galfan coated wire is available.We can manufacture gabion machine according to customer request.
GABION MESH MACHINE PRODUCT ADVANTAGE
1.It is touch screen control.
2,It has the function of frequency control of motor speed according
to different of wire diameter.
3,It has buffer function when speed increase or decrese in very
short time.
4,It can count output every day or every year.
5,It can save about 30% energy.
GABION MESH MACHINE SPECIFICATION
Model | Mesh size | Width | Wire diamater | Spindle Speed | Power of motor | Theoretic output |
(mm) | (mm) | (mm) | (r/min) | (kw) | (m/h) | |
JT-G23-60 | 60X80 | 2300 | 1.6-3.0 | 25 | 11 | 165 |
JT-G23-80 | 80X100 | 2300 | 1.6-3.0 | 25 | 11 | 195 |
JT-G23-100 | 100X120 | 2300 | 1.6-3.2 | 25 | 11 | 225 |
JT-G23-120 | 120X150 | 2300 | 1.6-3.5 | 30 | 11 | 255 |
JT-G33-60 | 60X80 | 3300 | 1.6-3.0 | 25 | 15 | 165 |
JT-G33-80 | 80X100 | 3300 | 1.6-3.2 | 25 | 15 | 195 |
JT-G33-100 | 100X120 | 3300 | 1.6-3.5 | 25 | 15 | 225 |
JT-G33-120 | 120X150 | 3300 | 1.6-3.8 | 20 | 15 | 255 |
JT-G43-60 | 60X80 | 4300 | 1.6-2.8 | 25 | 22 | 165 |
JT-G43-80 | 80X100 | 4300 | 1.6-3.0 | 25 | 22 | 195 |
JT-G43-100 | 100X120 | 4300 | 1.6-3.5 | 25 | 22 | 225 |
JT-G43-120 | 120X150 | 4300 | 1.6-3.8 | 20 | 22 | 255 |
GABION MESH MACHINE PACKING
Packing Details:plastic film outside for main machine,wooden box for accessories,or nude package or as customer demand.
Delivery Time:30 -35 working days after received customer's deposit.
![]() |
