Best Price Galvanized Steel Fence Panel Wire Mesh Welding Equipment
Wire Mesh Welding Machine Product Details
| Line wire feeding system | (1)Wire feeding system can send the steel bars to the welding
machine in tidy.When the main machine is being welded,the material
of the next reinforcing mesh can be placed at the same
time.Improved productivity.
(2)Famous servo motor (1.5kw) and planetary reducer for sending
longitude wires when welding,can save time. |
| Cross wire feeding system | (1)The cross wire feeding system adopts the invention patent,which
can carry 2000KG of steel bar weight.Reduced labor and cost
savings. |
| Welding electrodeds | (1)The welding electrode is connected to the transformer by single wire connection. The
conductive effect is better, the electric energy is used more
fully, and the electric energy and cost are saved.
(2)All connecting wires are solid copper plates.
(3)Welding electrodes are made of pure red copper and chromised
bronze ,durable,can bu used at least 3-6 months
|
| Mesh pulling system | (1)The reinforcing mesh conveying system is divided into 6meter and
12meter.
(2)It contains a roller conveyor,which is easy to pack reinforcing
mesh and convenient to load truck.
(3)We can design the conveying system length according to the
customer's requirements.
(4)It is controlled by servo motor (2kw)&planetary reducer and
air cylinders,advanced.
|
Wire Mesh Welding Machine Product Specification
Welding wire diameter range of the device is 6-12 mm, the mesh size
is 100-300mm, stepless adjustable. The maximum width of the welding
wire mesh is 2500mm (also according to customer requirements).
Welding host, an alarm device that can improve the safety level and
reduce the failure rate. The greatest degree of assurance of the
equipment running smoothly.
Wire Mesh Welding Machine Product Specification
Working Specification:
|
| Material | pre-straighten, low carbon cold-rolled wire or cold-drawn uncoated
wire |
| Max.mesh length (line wire length) | 12000 mm( According to the customer request) |
| Min.mesh length (line wire length) | 1500 mm |
| Max.mesh width (cross wire length) | 2500 mm |
| Min.mesh width (cross wire length) | 1500 mm |
| Line wire spacing | ≥100 mm, adjustable |
| Cross wire spacing | ≥100 mm, programmable adjustable |
Electronic parts specifications:
|
| Numbers of welding transformer | 12 |
| Numbers of electrode | 24 |
| Power supply voltage | 380 V – 50 Hz ( According to the customer request) |
| Total installed power | 15× 150 KVA
|
Wire Mesh Welding Machine Function features
1.Brake motor & reducer connect the principal axis directly.
2.Cast water-cooling transformer and lower welding electrode base.
3.Pure welding electrodes,30*30*50mm(5-12mm).
4.PLC control of cross wire space adjustment and welding current
adjustment.
5.Pre-straightened & pre-cut wires.
6.Touch screen interface.
7.Wire pre-load system.
